#887528 - 12/24/10 05:36 PM big block 590 purple shaft cam spec?
542GTX Offline
enthusiast

Registered: 03/11/07
Posts: 374
Loc: ONTARIO,CANADA
Does anyone have a cam card on a 590 purple shaft. I just bought one from my local dealership and it didn't come with a cam card. I need the spec to dial the cam in.
Thanks for any and all info
Kevin

Top
#887529 - 12/24/10 06:08 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
10sec440 Offline
super gas

Registered: 01/19/03
Posts: 1231
Loc: Mission BC
The specs are usually on the end of the box, but google is your friend...

Specifications: * Advertised duration: 312 intake/312 exhaust * Gross valve lift: .590 in. intake/.590 in. exhaust * Lobe separation: 106 degrees * RPM range: 3400 to 6900 * For super competition applications with manual or automatic transmissions with race converter. * Three-bolt

Depending on the rest of your combo, you will want to put it in between 102 and 106. GREAT cam, I ran 10.27 with one in a stock stroke pump gas 440,iron head 452. 3400lb Dart.
_________________________
10.15 at 130MPH Pump gas 440,3400lbs.

Top
#887530 - 12/24/10 07:21 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
Dodgem Offline
master

Registered: 03/21/08
Posts: 5664
Loc: Ontario, Canada
supposed to be 265/265 @ .050 the rest is above.

Top
#887531 - 12/24/10 07:43 PM Re: big block 590 purple shaft cam spec? [Re: Dodgem]
Sport440 Offline
master

Registered: 01/20/03
Posts: 5920
Loc: Canton, Ohio
Quote:

supposed to be 265/265 @ .050 the rest is above.






But its not! Its duration is actually 271/272 @ .050 thereabouts,

Reguardless, 265 or 272 install it at between 98* to 102 ICL for best performance in most apps. mike


Edited by Sport440 (12/24/10 08:13 PM)

Top
#887532 - 12/24/10 08:08 PM Re: big block 590 purple shaft cam spec? [Re: Sport440]
Dunnuck Racing Offline
mopar addict

Registered: 03/18/07
Posts: 3292
Loc: Northern Indiana
Mopar finally updated the cam chart.I'll see if I can attatch it,it has the "realworld" @.050 numbers.
Keith


Attachments

_________________________
www.dunnuckracing.com

Top
#887533 - 12/24/10 08:13 PM Re: big block 590 purple shaft cam spec? [Re: Dunnuck Racing]
542GTX Offline
enthusiast

Registered: 03/11/07
Posts: 374
Loc: ONTARIO,CANADA
Thanks guys for all the help.

Top
#887534 - 12/24/10 08:15 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
VernMotor Offline


Registered: 11/28/03
Posts: 7076
Loc: Mt.Vernon ,Ohio
I started out with my at 104 then 102 and now at 100 ..like it real well there 3600lb car
_________________________
Racing is not a Hobby,But a way of Life 2000-2001 Pacemakers Major JR Dragster Champion 2005 PRO Class Champion 2006 PRO Class Champoin 2011 Mo-Power Pro champion (Jenni Vernon)

Top
#887535 - 12/24/10 08:16 PM Re: big block 590 purple shaft cam spec? [Re: Sport440]
Dodgem Offline
master

Registered: 03/21/08
Posts: 5664
Loc: Ontario, Canada
Quote:

Quote:

supposed to be 265/265 @ .050 the rest is above.






But its not! Its duration is actually 271/272 @ .050 thereabouts,

Reguardless, 265 or 272 install it at between 98* to 102 ICL for best performance in most apps. mike






we had my friends in at 104 and I talked him into 100 and it was snappier at 100

Top
#887536 - 12/24/10 09:57 PM Re: big block 590 purple shaft cam spec? [Re: Dodgem]
542GTX Offline
enthusiast

Registered: 03/11/07
Posts: 374
Loc: ONTARIO,CANADA
What do you guys recommend for valve springs?

Top
#887537 - 12/24/10 10:10 PM Re: big block 590 purple shaft cam spec? [Re: Dunnuck Racing]
6bblFLASH Offline
master

Registered: 01/20/03
Posts: 3203
Loc: N.E. Ohio
Some of those spec.s are quite a bit different than what I remember WOW
'
I too have run and am running the .590.
Lots of people say "theres better cams" I`ve just never found one.

Is that really a 114c/l on the 484hyd?
I`m putting a blower on my 383 and was looking for a cam with 112--114 lobe centers ,but it already has a 484 which IS a 114?????
I thought the 484 was 110 c/l?


Attachments



Edited by 6bblFLASH (12/24/10 10:12 PM)
_________________________
70` Cuda`,440 6BBL Jerico,Dana 4.56 Still on 93 Pump Gas 9.87 @ 136/1.31-60ft.`09 Mopar Nationals PASSON PERFORMANCE "Stick-Shift" Champ! 2013 StickShift Challenge Winner@ Mopar Nationals!

Top
#887538 - 12/25/10 12:05 AM Re: big block 590 purple shaft cam spec? [Re: 6bblFLASH]
SILVER67 Offline
mopar

Registered: 02/04/06
Posts: 575
Loc: Liverpool, NY
Should be interesting to see what the .590 does in my upcoming build and the low numerical gears....

Michael
_________________________
Competition Wedge Engines Brewerton, NY

Top
#887539 - 12/25/10 01:47 AM Re: big block 590 purple shaft cam spec? [Re: SILVER67]
mike s Offline
top fuel

Registered: 01/07/07
Posts: 1618
Loc: Mi,U.S.A.
Both the 509 and the 484 have been revised(lobe center change to 112 and 114) in the last few years for better "street" manners.As far the 590 goes,you can do better but I know lots of folks that still like the old warhorse.
_________________________
Leave the gun.......take the Cannoli's....Mike

Top
#887540 - 12/25/10 02:06 AM Re: big block 590 purple shaft cam spec? [Re: mike s]
70AARcuda Offline
master

Registered: 01/20/03
Posts: 9185
Loc: las vegas
there are two versions of the 484/509 cam for
BB...108 and 114 center line

SB only shows the 484 cam with both Center lines available..

but my catalog is a couple years old
_________________________
Tony 70 AARCuda Vitamin C 71 Dart Swinger 360 10.318 @ 128.22(10-04-14Bakersfield) 71 Demon 360 10.720 @120.66 (9-08- 2012 @ Sacramento) 71 Duster 360 (10.65 @ 123.22 10/04/14 Bakersfield)

Top
#887541 - 12/25/10 06:32 AM Re: big block 590 purple shaft cam spec? [Re: 70AARcuda]
572charger Offline
pro stock

Registered: 03/30/03
Posts: 1579
Loc: pa
590 in at 102 to 100 works killer in a b body [heavy car] in a 3600 e body with ye old trws 2295s 590 mild ported 906s, 850 holley, torker intake turbo action 3800 with 456s in the dana goes 10.80s all day long back in 1988-1994 6 years of racing and its still runnin with out a rebuild to this day
_________________________
606 hemi pump gas best 9.60 at 142mph on motor 05 hemi daytona 1500 go-mango 4wd quadcab 2007 hotrod mag pump gas drags runner up

Top
#887542 - 12/25/10 10:08 AM Re: big block 590 purple shaft cam spec? [Re: 572charger]
clovis Offline
enthusiast

Registered: 03/12/08
Posts: 329
Loc: Kentucky
Here is the card that I got from the Tech line guys. As everyone has said and the new paperwork details the duration at .050 is actually 271. This just gives you the opening and closing points.

312 Mechanical: P4120663
Duration Intake Nominal 312 Duration Exhaust Nominal 312
Duration Intake @ .050 265 Duration Exhaust @ .050 265
Intake Lobe Centerline 104 ATDC Exhaust Lobe Centerline 108 BTDC
Lobe Separation Angle 106 Overlap 100
Intake Opens 52 BTDC Exhaust Opens 84 BBDC
Intake Closes 80 ABDC Exhaust Closes 48 ATDC
Intake Lift .590 Exhaust Lift .590
Note: as installed on 104 centerline per Chrysler
_________________________
'75 Duster 451 906/590/2-660 10.75/126 New combo-Stage VI/590/1050 6.23/111 9.82/135 "For by grace you have been saved through faith. And this is not your own doing; it is the gift of God,"

Top
#887543 - 12/25/10 10:26 AM Re: big block 590 purple shaft cam spec? [Re: clovis]
S/ST 3040 Offline
master

Registered: 07/14/06
Posts: 4595
Loc: On the south side of Nowhere
I've posted this before but, this is what I've found on the MP/DC Purple SOLID cams:

Their advertised durations use timing events @ .015"

I typically find, duration @ .020" is 8 less. i.e. 312/590 cam is 304 @ .020"

Duration @ .050" is 32 less than duration @ .020"

So the 312/590 cam looks like this:

304 @ .020"
272 @ .050"

I hope that helps.
_________________________


349" OEM Head, 1.88" valve, 9.24:1 Pump Gas
1.322 60 ft. 6.18 @ 109.01 9.86 @ 131.06 MPH (so far)
Non-Conformist

Top
#887544 - 12/25/10 01:01 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
AAR-B4 Offline
mopar

Registered: 09/29/06
Posts: 671
Loc: SW Ohio
Quote:

What do you guys recommend for valve springs?



Comp 928 or K-Motion 850. My choices.

Top
#887545 - 12/25/10 02:40 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
shoebox Offline
super stock

Registered: 11/20/05
Posts: 807
Loc: mckinney texas
i hate to hyjack but it sounds like this cam would be good for me too. im looking for a 10sec timeslip..what do you think?
74 dart sport all steel 3300lbs empty?
440 2295s 070 in the hole
260cfm at 600 452s small valves
590 cam?
victor intake and 1050 dominator 2 inch proparts
9inch tci race converter 4k stall. 3.70 gear now (can change to ???) must run on pump gas/torco mix maybe. what rpms are safe with the heavy slugs? and whats the shift point? any help would be appriciated thanks gus
_________________________
74 dart sport 440 www.Csucarbs.com

Top
#887546 - 12/25/10 02:59 PM Re: big block 590 purple shaft cam spec? [Re: 542GTX]
440Jim Offline
I Live Here

Registered: 01/19/03
Posts: 15602
Loc: Southern Maryland
In addition to the actual duration at 0.050", this is what Dwayne Porter measured on one a few years ago.

MP .590 cam, actual measurements-
DUR. @
.020=303.5
.050=270.5
.100=235.0
.150=205.0
.200=177.0
.250=148.5
.300=117.0
.350=76.0
lobe lift@TDC @105 ICL=.140
LSA 106

Top
#887547 - 12/25/10 03:01 PM Re: big block 590 purple shaft cam spec? [Re: shoebox]
440Jim Offline
I Live Here

Registered: 01/19/03
Posts: 15602
Loc: Southern Maryland
Quote:

440 2295s 070 in the hole
260cfm at 600 452s small valves



Gus,
I have a feeling the 0.590" cam might like more compression ratio than you have. What is the combustion chamber size on your set of 452 heads? They vary a lot.
_________________________
