#2323514 - 06/19/17 09:02 AM Electric Fuel Pump - 600HP
GTX MATT Offline
master

Registered: 06/05/06
Posts: 4787
Loc: CT
Since I found my fuel pressure is dropping pretty low at WOT I need to re-plumb and switch to an electric pump. My setup SHOULD be in the 500 HP neighborhood, so looking for a pump that would be good to 600. I'm planning to run it dead headed since I just plumbed the engine half with stainless hose and anodized fittings made of gold.

I was looking at the Mallory 140 and the Carter 4601HP. Anyone think the Carter is enough? It's only rated for 100 GPH, everyone says they last forever and I have a buddy that has been running one dead headed forever, no problems and super quiet.

I'm open to any other suggestions.
_________________________
Now I need to pin those needles, got to feel that heat Hear my motor screamin while I'm tearin up the street

Top
#2323520 - 06/19/17 09:18 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
B3422W5 Offline
I Live Here

Registered: 01/20/03
Posts: 10002
Loc: Portage,michigan
Holley black worked excellent on my old 9.80's car(3350 pounds race weight). Ran deadheaded, lots of street time.
In fact, upgraded to a big fancy system and gained zero.
I was well over 600 horse, probably 650.


Edited by B3422W5 (06/19/17 10:26 AM)
_________________________
69 Dart GTS, performance upgrades in progress
11.26@ 118.40 best so far. Stock 360 shortblock with eddie heads.

Top
#2323526 - 06/19/17 09:33 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
rowin4 Offline
master

Registered: 06/30/05
Posts: 5955
Loc: gulfport, ms, west mi
Holley Black, #8an braided line dead headed.
_________________________
it's ok to butt heads, just don't do it with a butthead

Top
#2323541 - 06/19/17 09:59 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
an8sec70cuda Offline
I Live Here

Registered: 01/19/03
Posts: 10426
Loc: Marion, South Carolina [><]
Another option...Aeromotive 11203 street rod pump, deadheaded, -8 line. Fed my 800+ hp hemi to run 9.50s at 140 mph at 3800 lbs w/ no trouble. Put a lot of street time on it too.
_________________________
CHIP
'70 hemicuda...8.91 at 150.5 mph street car...Mopar Action feature Dec. '14
'69 road runner 446" w/ Indy SRs
'69 road runner 440-6, 4 speed...Dad's ride
'71 Demon 340 resto project
'01 Ram 2500 QCSB 4x4 Cummins...toy hauler
'16 Grand Caravan SXT...baby hauler

Top
#2323558 - 06/19/17 10:29 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
AndyF Offline
Too Many Posts

Registered: 01/20/03
Posts: 23815
Loc: Oregon
600 hp requires 300 lbs of fuel per hour which is 50 gallons per hour.

Top
#2323565 - 06/19/17 10:49 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
rickseeman Offline
pro stock

Registered: 01/18/12
Posts: 1405
Loc: Little Rock, Arkansas
I prefer the Carter. It's a Mopar thing.
_________________________
2011 Drag Pak Challenger

Top
#2323576 - 06/19/17 11:12 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
GTX MATT Offline
master

Registered: 06/05/06
Posts: 4787
Loc: CT
My original plan was actually a Holley Black, but I keep reading about how the Holley pumps are terrible and don't last long. And really prone to leaks. And I know they can be pretty noisy. It seems the one with the most gripes is the Blue though, not the Black. Is there a significant difference in the quality of the two?


Edited by GTX MATT (06/19/17 11:13 AM)
_________________________
Now I need to pin those needles, got to feel that heat Hear my motor screamin while I'm tearin up the street

Top
#2323577 - 06/19/17 11:15 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
gregsdart Offline
master

Registered: 01/21/03
Posts: 8218
Loc: Frostbitefalls (Rocky&Bullwink...
I just bought a Carter 4601, figure my deal will make 470 to 500 hp. It should be able to handle what you expect for power, as long as you have a good system.
_________________________
GREG
Educated at SHK U
Measure with yardstick
mark with chalk
cut with torch!



528 cubic inch alky injected 440-1 wedge, 3055 race weight.
8.779 at 153.16 mph. 1.289 60 ft. density altitude 1617 feet. Best 60 ft 1.24

Top
#2323582 - 06/19/17 11:24 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
Chris2581 Offline


Registered: 01/19/03
Posts: 6531
Loc: Jacksonville, FL
I'm running a Carter also,My 440 is a bit over 500HP,Deadheaded too.
_________________________
Nautilus Racing-
We use Superformance gaskets and Turbo Action converters/products.

Top
#2323584 - 06/19/17 11:26 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
gregsdart Offline
master

Registered: 01/21/03
Posts: 8218
Loc: Frostbitefalls (Rocky&Bullwink...
The volleys (blues at least) are noisy as all get out. I would rather run two Carters, if one won't handle it, which I believe it will anyway.
_________________________
GREG
Educated at SHK U
Measure with yardstick
mark with chalk
cut with torch!



528 cubic inch alky injected 440-1 wedge, 3055 race weight.
8.779 at 153.16 mph. 1.289 60 ft. density altitude 1617 feet. Best 60 ft 1.24

Top
#2323591 - 06/19/17 11:42 AM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
BradH Offline
I Live Here

Registered: 01/30/03
Posts: 13634
Loc: Valhalla... eventually
Originally Posted By GTX MATT
My original plan was actually a Holley Black, but I keep reading about how the Holley pumps are terrible and don't last long.

LOTS of down feedback on Summit about the Holley black pumps. Enough that I decided to buy another Mallory 140, even though I wasn't happy that the price had increased so dramatically since I'd purchased my last one. Not sure if that's because MSD bought Mallory, or if all pumps have gone up a lot since about 10 years ago.
_________________________
"Do what you can, with what you have, where you are." - Theodore Roosevelt

“Money talks. Sometimes all it says is ‘Goodbye’.” - Unknown

Top
#2323626 - 06/19/17 12:54 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
Cab_Burge Online   content
I Win

Registered: 08/23/03
Posts: 30542
Loc: Bend,OR USA
I've use a bunch of different electric pumps over the years on race cars, some no good and some better ones that are real good thumbs
You know you will probably want to make more power later so step up now and buy a good pump now twocents
I use Magnafuel pumps now on all my serious cars, the higher HP motors get the bigger pumps thumbs work
People forget about the amount of pressure on the pump from the weight of the fuel in the line on the launch on cars that have the pump and fuel tank in the rear of the car work It doesn't take more than about two seconds at WOT to drain both fuel bowls shock work
Having 18 lbs. of pressure between the pump and regulator is way better than having 14 lbs. up twocents
IHTHs


Edited by Cab_Burge (06/19/17 01:05 PM)
_________________________
Mr.Cab Racing and winning with Mopars since 1964. (Old F--t, Huh)

Top
#2323644 - 06/19/17 01:36 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
humpty Offline
enthusiast

Registered: 10/17/07
Posts: 353
Loc: Minnesota, USA
I'm running a deadheaded Mallory 140 in a 600hp SB. When I bought it I was running a 430hp SB but figured the extra capacity wouldn't hurt. It's been 8 years now with no issues. Still primes quickly, holds steady pressure, and is quiet compared to the Holley's.
_________________________

72 Duster - 408ci W2, 10.18@131. Shooting for 10.0's in 2018!
https://m.youtube.com/watch?v=Q4P51j38-MI

Top
#2323681 - 06/19/17 02:42 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
fast68plymouth Offline
I Live Here

Registered: 01/20/03
Posts: 10705
Loc: So. Burlington, Vt.
The Mallory 140 was always one of my favorite street/strip, mild bracket race pumps......... But....... Now they're $306.

I suppose if the quality it as good as it was in the past it's probably still worth it.

A Summit coupon would def help take a little of the sting out of it.
_________________________
68 Plymouth Satellite, 383, stock 906's, 3550lbs, 11.18 @ 123, 1.51 60'
WD- Comp Cams / Indy Cylinder Heads

Top
#2323727 - 06/19/17 04:04 PM Re: Electric Fuel Pump - 600HP [Re: an8sec70cuda]
Triple Threat Offline


Registered: 01/19/03
Posts: 6183
Loc: Renton Washington
Originally Posted By an8sec70cuda
Another option...Aeromotive 11203 street rod pump, deadheaded, -8 line. Fed my 800+ hp hemi to run 9.50s at 140 mph at 3800 lbs w/ no trouble. Put a lot of street time on it too.


I second this recommendation, I just purchased one for my new car.
_________________________
-Dustin
392" G3 Hemi
1.37, 6.17@111, 9.74@136.9

Top
#2323743 - 06/19/17 04:30 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
fast68plymouth Offline
I Live Here

Registered: 01/20/03
Posts: 10705
Loc: So. Burlington, Vt.
One of my customers that does a lot of stroker motor builds and installs uses that Aeromotive pump a lot. I think he said he's installed about 15 of them, only one issue, which was somewhat self inflicted(no prefilter).

Based on that info, I recommended one to someone who wanted to replace their old Holley blue before heading to Drag Week.
Took out the blue, put in the Aeromotive.

I think he said it made it through the first day, started getting really loud, and the pressure was dropping right off.
Put the old Holley blue back on...... Which was still going strong at the end of Drag Week.

Seems like there are those kinds of stories for just about every brand out there I guess.
_________________________
68 Plymouth Satellite, 383, stock 906's, 3550lbs, 11.18 @ 123, 1.51 60'
WD- Comp Cams / Indy Cylinder Heads

Top
#2323757 - 06/19/17 05:09 PM Re: Electric Fuel Pump - 600HP [Re: fast68plymouth]
Triple Threat Offline


Registered: 01/19/03
Posts: 6183
Loc: Renton Washington
Originally Posted By fast68plymouth

Seems like there are those kinds of stories for just about every brand out there I guess.


Most definitely, I've had bad luck with Magnafuel, which the majority of people love, and no issues with my Aeromotive stuff.

There are lemons out there for all brands.
_________________________
-Dustin
392" G3 Hemi
1.37, 6.17@111, 9.74@136.9

Top
#2323912 - 06/19/17 09:47 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
383man Offline
Too Many Posts

Registered: 01/19/03
Posts: 26624
Loc: Balt. Md
Holley black here with 3/8 line. I have had the Holley black pump on my 63 since 2011 and never a problem. I also had the Holley red pump on it from 2003 to 2011 and it also never had a problem. I have only use Holley pumps all my life and only once had a pump go up on my sons Dart which had the red pump on it and it went bad around 2010 and it had been on his car since 1997. Ron


Edited by 383man (06/19/17 09:49 PM)
_________________________
My car...63 Sport Fury Max Wedge wanna be street car..with new 493 pump gas full exh eng.......10.76 @ 124.49 ! ! ! My page on the cool 62-65 Mopar site ! http://www.1962to1965mopar.ornocar.com/mmo82008.html

Top
#2323916 - 06/19/17 09:53 PM Re: Electric Fuel Pump - 600HP [Re: fast68plymouth]
SILVER67 Offline
super stock

Registered: 02/04/06
Posts: 753
Loc: Liverpool, NY
Mallory 140 for over 5 years.
Using Holley 12-803 return regulator
Street
Bracket race
_________________________
Competition Wedge Engines Brewerton, NY

Top
#2323928 - 06/19/17 10:16 PM Re: Electric Fuel Pump - 600HP [Re: GTX MATT]
451Mopar Offline
master

Registered: 05/19/08
Posts: 4921
Loc: Aurora, Colorado
I have had problems with the Edelbrock Quiet-Flo pumps.
I guess MSD bought out Mallory? Wow the prices doubled!
I have an old Mallory 250 GPH that has been in the car at least 15-years, but back then they were about $250? $458 for a new one is crazy.
